LS3612 Series Hinges - 165 Degree Opening - Bi-Folding Doors
165 degree hinges for bi-folding cabinet doors
Technical Specifications
LS3612 hinges constructed with steel base material and polymer dampening components. Opening angle fixed at 165 degrees for bi-folding door configurations. Integrated soft-close mechanism activates at 15 degrees from closed position. Mounting uses concealed cup design with 35mm bore diameter. Load capacity supports doors up to 10 lbs per pair. Finish: nickel-plated for corrosion resistance.
Application & Performance
Suitable for bi-folding doors on kitchen cabinets, bathroom vanities, and pantry units. 165 degree opening allows full panel access without door overlap. Soft-close function reduces slam impact by 80% at contact. Rated for 20,000 open-close cycles. Corrosion-resistant plating withstands high-humidity environments. Limitation: requires precise 35mm cup hole alignment for level operation.
Specifications
Detailed Specifications & Suitability
| Property | Value |
|---|---|
| Model | LS3612 |
| Opening Angle | 165 degrees |
| Door Type | Bi-folding |
| Cup Diameter | 35mm |
| Load Capacity | 10 lbs per pair |
| Finish | Nickel-plated |
| Cycle Rating | 20,000 cycles |
