H/0805 LS3612 Hinges - Door and Frame Attachment - cabinets
LS3612 hinges for cabinet door and frame attachment
SKU: ghcabinetry_knobs-and-pulls_4199
soft-closekitchen-islandbathroom-vanity
Technical Specifications
LS3612 hinges attach cabinet doors to frames. Construction: stamped steel with zinc plating for corrosion resistance. Opening angle: 110°. Cycle test: 21,000 open/close cycles. Load capacity: 35-75 lb per pair. Installation: 3-hole screw pattern, overlay configuration. Cup diameter: 35mm. Frame side: adjustable height ±2mm.
Application & Performance
Suitable for frameless and face-frame cabinetry. Overlay installation positions door 1/2-inch forward of frame edge. Supports full overlay doors up to 3/4-inch thick. 110° opening provides cabinet access without frame interference. Rated for 21,000 cycles under 35-75 lb load. Zinc plating resists humidity in kitchen and bath environments.
Contact for price
Always free deliveryWithout minimum shipping cost
Specifications
ModelLS3612
TypeDoor and Frame Attachment Hinges
Opening Angle110°
Load Capacity35-75 lb per pair
Cycle Rating21,000 cycles
MaterialZinc-plated steel
Cup Diameter35mm
InstallationOverlay, 3-screw mounting
AdjustmentHeight ±2mm
descriptionHINGES-LS3612 Door and Frame Attachment
Detailed Specifications & Suitability
| Property | Value |
|---|---|
| Model | LS3612 |
| Type | Door and Frame Attachment Hinges |
| Opening Angle | 110° |
| Load Capacity | 35-75 lb per pair |
| Cycle Rating | 21,000 cycles |
| Material | Zinc-plated steel |
| Cup Diameter | 35mm |
| Installation | Overlay, 3-screw mounting |
| Adjustment | Height ±2mm |
