LUBAN H/0806 - UQC60 Upward Opening Hinges - cabinets
Upward opening hinges for horizontal cabinet doors
Technical Specifications
Construction: Steel hinges with UQC60 model designation. Designed for upward lift motion on horizontal opening doors. Mounting: Surface-mounted with screw holes for frame or inset installation. Mechanism: Integrated lift-assist spring and soft-close damper. Load capacity: Supports doors up to 15kg per pair. Opening angle: 90-110 degrees. Finish: Powder-coated for corrosion resistance. Compatibility: Luban H/0806 cabinetry systems.
Application & Performance
Suitable for overhead cabinet doors requiring vertical lift access, such as kitchen uppers and pantry storage. Horizontal door configuration prevents swing obstruction in tight spaces. Soft-close damper reduces slam force by 80%. Lift-assist spring enables single-hand operation on doors 18-24 inches wide. Rated for 20,000 cycles. Not for full-overlay doors exceeding 30 inches height. Requires level frame alignment for even lift.
Specifications
Detailed Specifications & Suitability
| Property | Value |
|---|---|
| Model | UQC60 |
| Type | Upward opening hinges |
| Door Orientation | Horizontal opening doors |
| Material | Steel |
| Opening Angle | 90-110 degrees |
| Load Capacity | 15kg per pair |
| Cycle Rating | 20,000 cycles |
| Finish | Powder-coated |
| Product Code | H/0806 |
